Overview
The PADS-USB-HUB attaches to the USB port of any PC-based audio server and provides up to three channels of stereo audio plus a control communication channel, transported over Cat5 cable to PADS™ audio endpoints. Independently powered, it also feeds 12-15 VDC power to the endpoints.
The server sees the three channels as three native USB audio DACs - any audio application can open them and send music, with no special drivers. The control channel appears as a virtual COM port with a very simple API, carrying user commands, endpoint status and music-captioning information.
Features & benefits
- Three RJ-45 ports for Cat5 connection to audio endpoint zones
- Three native USB stereo DACs - no special drivers
- Built-in four-port USB hub, USB 1.1 full-speed (12 Mbps)
- On-board processor handles USB and endpoint control
- Each port powers endpoints with 12-15 VDC unregulated
- Control channel as virtual COM port with simple API
- LED status indicator
Applications
- PC-based background-music servers
- Multi-zone retail and hospitality audio
- Music systems with captioning displays
